SPECS
POWER DEVICE
Type
none
MODEM
Interface Type
CardBus
Connectivity Technology
wired
Max Transfer Rate
56 Kbps
Transmission Mode
full-duplex
56K Technology
K56Flex, V.90
Protocols & Specifications
Bell 212A, ITU V.22, ITU V.22bis, ITU V.29, ITU V.32, ITU V.32bis, ITU V.34, ITU V.90, ITU V.17, ITU V.23, ITU V.27ter, k56Flex, AT&T V.32terbo, Hayes AT command set
Fax Compatibility
G3
Max Fax Transfer Rate
14.4 Kbps
Cellular Protocol
AMPS, GSM
Error Correction Protocol
ITU V.42, MNP-2, MNP-3, MNP-4
Form Factor
internal
Bus
CardBus
Type
network / modem combo
Data Compression Protocol
ITU V.42bis, MNP-5
Cellular Protocol
GSM, AMPS
NETWORKING
Type
Network adapter
Connectivity Technology
wired
Data Link Protocol
Ethernet, Fast Ethernet
Compliant Standards
IEEE 802.3, IEEE 802.3u
Data Transfer Rate
100 Mbps
MISCELLANEOUS
Mounting Kit
not required
Package Type
retail
COMMUNICATIONS
Data Compression Protocol
ITU V.42bis, MNP-5
Error Correction Protocol
ITU V.42, MNP-2, MNP-3, MNP-4
INTERFACE PROVIDED
Gender
female
Connector Qty
1, 2
Qty
1
TELECOM
Compliant Standards
Hayes AT command set
SYSTEM REQUIREMENTS
OS Required
Artisoft LANtastic, Banyan VINES, DEC PathWorks, IBM OS/2, Microsoft LAN Manager, Microsoft Windows 3.x/95/98, Microsoft Windows NT 3.51 or later, Novell NetWare
ENVIRONMENTAL PARAMETERS
Min Operating Temperature
32 °F
Max Operating Temperature
149 °F
Humidity Range Operating
0 - 95%
HEADER
Brand
Xircom
Product Line
Xircom RealPort CardBus
Model
Ethernet 10/100 + Modem 56
Packaged Quantity
1
Compatibility
PC
AUDIO OUTPUT
Type
none
MOBILE BROADBAND
Cellular Protocol
AMPS, GSM
DIMENSIONS & WEIGHT
Width
2.1 in
Depth
3.4 in
Height
0.4 in
Weight
1.27 oz
AUDIO INPUT
Type
none
SOFTWARE
Type
Drivers & Utilities
EXPANSION SLOTS
Type
none
SLOT REQUIRED
Type
CardBus
Form Factor
type III
Total Qty
1
SERVICE & SUPPORT
Type
limited lifetime warranty
SERVICE & SUPPORT DETAILS
Type
limited warranty
Service Included
parts and labor
Location
carry-in
Full Contract Period
