Model
Brand
ECS
Model
761GX-M754 (3.0A)
Supported CPU
CPU Socket Type
754
CPU Type
Athlon 64 / Sempron
FSB
800 MHz
Chipsets
Chipset
SiS 761 GX
South Bridge
SiS 964
Memory
Number of Memory Slots
2x184pin
Memory Standard
DDR 400
Maximum Memory Supported
2GB
Expansion Slots
PCI Express x16
1 x PCI Express x16
PCI Slots
3 x PCI Slots
Other Slots
1 x CNR
Storage Devices
PATA
2 x ATA100 4 Dev. Max
SATA 1.5 Gb/s
2 x SATA 1.5 Gb/s
SATA RAID
0/1
Onboard Video
Onboard Video Chipset
SiS Mirage1 Graphics
Onboard Audio
Audio Chipset
ADI AD1888
Audio Channels
6 Channels
Onboard LAN
LAN Chipset
Realtek 8201CL PHY
Max LAN Speed
10/100Mbps
Rear Panel Ports
PS/2
2
COM
1
LPT
1
Video Ports
D-Sub
USB 1.1/2.0
4 x USB 2.0
Audio Ports
3 Ports
Internal I/O Connectors
Onboard USB
2 x USB 2.0 connectors support 4 ports
Physical Spec
Form Factor
Micro ATX
Dimensions (W x L)
9.6" x 8.1"
Power Pin
24 Pin
